Product information
Model 8160
Utensil Washer 8160: perfect size for the industry
Product features
| Wash area (WxHxD) mm | 1340x870x1000 |
| Outer dimensions (WxDxH1/H2) mm | 1590x1115x1961/1961 |
| Euronorm crate 400x600 mm | 8 |
| Gastronorm crate 500x500 mm | 4 |
| Trays per wash 400x600 mm | 64 |
| Trays per wash 600x800 mm | 42 |
| 40L Industrial mixer bowls | 3 |
| 60L Industrial mixer bowls | 2 |
| 80L Industrial mixer bowls | 2 |
| 100L Industrial mixer bowls | 1 |
Options
Very large wash volume:
H (870 mm) * W (1340 mm) * D (1000 mm)
- Automatic roll curtain opening system
- Industrial version.
- Individual adaptation possible.
General data
| Wash Tank | 165ltrs |
| Wash Time (min) | 2+4+6 |
| Rinse Tank | 31ltrs |
| Wash Pressure | 0.9 - 1.9 Bar |
| Water Consumption per wash | 16ltrs |
| Rinse Pressure | 1.1 Bar |
| Wash Pump capacity | 2 x 950 |
| Wash Pump | 2 x 2.7Kw |
| Wash Temp | 55°c |
| Current Rating | 32 Amp |
| Rinse Temp | 85°c |
| Connection | 18.5Kw |
Dimensions
| Wash Area W x H x D mm | 1340 x 870 x 1000 |
| Machine H1 x H2 x W x D | 1961 x 1961 x 1590 x 1115 |
Capacity
| Euronorm crates 400 x 600 | 8 |
| Plates 600 x 400 | 64 |
| Plates 600 x 460 | 42 |
| Plates 600 x 800 | 42 |
| Gastronomy tray 500 x 500 | 3 |
| 60 L Bowl H 511 x ø 575 | 2 |
| 80 L Bowl H 515 x ø 645 | 2 |
| 100 L Bowl H 558 x ø 685 | 1 |
Installation
| Voltage Standard | 3N ~ 50 Hz 400V+ 0 + PE |
| Max. power/main fuses | 18.5kw |
| Heat Elements | 32A |
| Power cable (standard) | 1x6.0kW + 2x6.0kW |
| Water connection, dimension | 5x4² x 2500mm |
| Water connection, pressure | 1/2” RG, 1.5 - 6dyn bar |
| Water connection, temperature | 1/2” x 1600mm, 56°C. |
| Drain dimension | Ø40 mm. |
| Other voltage on request | More than 8°dH we rec- |
